Bluetooth-Enabled Upper-Arm Blood Pressure Monitor

Kangfu Medical's high-quality Bluetooth-Enabled Upper-Arm Blood Pressure Monitor provides audio playback for every reading, eliminating the need to squint at the screen. The result indicator uses a clear three color light bar instead of blurry symbols, so you can immediately know if your pressure is in the green, yellow, or red area. The IP21 protection level can resist dust and splashes, making it safe for daily handling near sinks or damp bathroom counters.

Feature

Run CS87 on battery for cordless use, or plug it into an AC port for fixed sessions. Automatic shutdown can retain charge, with no fixed time limit for measurement, suitable for patients who need an additional few seconds to relax. The Bluetooth application synchronizes historical data directly to your phone, creating a searchable timeline that you can share with clinical doctors during remote reviews.

The design of CS87 can withstand storage temperatures ranging from -20°C to +55°C and up to 95% relative humidity, making it suitable for transportation and storage in various climatic conditions. This sturdy specification ensures that the monitor can maintain its functionality even in spaces with limited control, such as vehicles or storage cabinets.

The power comes from four AA batteries or a USB Type-C port, and users can choose between cordless mobility or fixed use. The device will automatically shut down after 120 seconds of inactivity to preserve battery life, while the low voltage icon will appear before the battery is depleted.

The standard cuffs can accommodate arm circumferences ranging from 220mm to 420mm, covering various adult arm sizes. The protection level of the host is IP21, which means it can resist dust entering and vertical water droplets, so accidental splashing or dusty surfaces will not affect operation.

The Bluetooth-Enabled Upper-Arm Blood Pressure Monitor supports mmHg and kPa, and switching between them only requires long pressing the settings button. User selection is equally simple, with a dedicated user button before each measurement to switch between Person 1 and Person 2, making shared use frictionless.

Each completed measurement will be announced in the form of sound, without the need to immediately view the display during or after the loop. This is particularly useful for users with visual limitations or those who prefer to close their eyes and stay relaxed while reading.

Using the oscilloscope method, the monitor measures systolic blood pressure from 0 to 299 mmHg and pulse rate from 40 to 180 beats per minute. The clinical accuracy of blood pressure is maintained at ±3 mmHg, and the clinical accuracy of pulse is maintained at ±5%, ensuring reliable readings over a wide physiological range.

CS87 maintains separate storage for two users, with each storage capable of storing up to 120 readings. In addition to simple storage, the device also automatically calculates the average of three measurements from the most recent session, providing each user with a reliable daily baseline without the need for manual tracking or mental calculation.

Technical Specifications

Customization Process

1. Requirement confirmation

Confirm the Bluetooth-Enabled Upper-Arm Blood Pressure Monitor function configuration (Bluetooth version, APP docking, data storage, voice, unit switching), appearance color, silk screen logo, packaging scheme, and target sales market.

2. Plan evaluation

Evaluate the feasibility of software and hardware, molds, minimum order quantity, delivery time, and output a quotation and project schedule.

3. Sample making

Hardware prototype debugging, completion of logo silk screen printing, appearance, and packaging sampling; Synchronize debugging of Bluetooth data transmission and integration with mobile apps.

4. Prototype confirmation

The customer checks the functionality, appearance, and packaging of the prototype, and confirms the stability of the Bluetooth connection and the effectiveness of data synchronization.

5. Formal production

Incoming inspection of components, SMT surface mount welding, and assembly of the entire machine; Complete blood pressure accuracy calibration, Bluetooth communication, full function testing, and aging testing; Appearance inspection.

6. Packaging and shipment

Complete packaging according to customized plans, conduct finished product inspections, and arrange shipment.

Target audience

1. Bluetooth-Enabled Upper-Arm Blood Pressure Monitor Suitable for people with hypertension and hypotension, long-term monitoring of blood pressure at home, and Bluetooth synchronous measurement data;

2. For middle-aged and elderly people, it is convenient for their children to remotely view blood pressure records;

3. For high-risk populations of cardiovascular and cerebrovascular diseases, continuous monitoring of blood pressure changes is necessary;

4. Corporate health gifts and community health screening;

5. Multiple members of the family share and automatically distinguish data records from multiple users.

Reminder: Measurement data is for health reference only and cannot be directly used as clinical diagnostic basis; The measurement results of arrhythmia users are for reference only and cannot replace medical diagnostic equipment.

Certification and Qualifications

1. Medical Device Certificate

Domestic Medical Device Registration Certificate and Production License; EU MDR CE; US FDA; UKCA, UK; Australian TGA; The blood pressure performance meets ISO 81060 2.

2. Electrical & Electromagnetic Compatibility

Medical Safety Standard IEC 60601 1; EMC EN60601 1 2； Bluetooth module FCC ID.

3. Environmental trade certificates

RoHS, REACH.

FAQ

Q1: Why does the irregular heartbeat symbol appear after some measurements?

The icon pops up when pulse rhythm varies over 25% from average during testing. It's only a reminder, not a diagnosis. Consult a doctor if the symbol shows frequently.

Q2: Can two people use the same device without mixing up their records?

Yes. The CS87 has a User key to switch User 1/2. Each owns independent 120-group storage and separate 3-reading average calculation, no mixed data.

Q3: How do I know when the batteries need replacing and what type should I use?

A low-battery icon reminds you to swap all four AA alkaline batteries together; never mix old/new or different brands. Remove batteries if the CS87 will sit unused over 3 months to avoid leakage.

Q4: Is the device waterproof and can I clean it with any household cleaner?

The CS87 is IP21 (dust & drip resistant only, not submersible). Wipe the machine with a damp cloth plus mild neutral detergent and dry fast. Do not use alcohol, thinner or other volatile solvents.
